Moondrop Rays

In the Box:
1x Moondrop Rays
1x Cable
1x USB-C to A Extended Cable
1x Storage Bag
1x Ear-tips (3pairs)
1x User Manual
1x Certificate

Warranty:
1 year

Features
Visual Multi-point Parametric Tuning, Effortlessly Customization, Personalized Customization for All Games.
Incorporates Professional Hi-Fi Acoustics Technology.
One-button Setting / Switching, Fine-tune with E-sports Players, Build-in Tune Sharing and Downloading Community.
Brand-new Tuning Interface, More Professional, More Accurate, Expand the Possibility of Game Tuning.
One-Click EQ, Easy to Use.
HiFi-class Game Sound Card, Clearer Imaging More Accurate, Positioning Richer Details.
Support Online WEB and APP Tuning, Built-in DSP Can Store Memory Tuning.
Hardware Al Noise Cancellation Microphone, Embedded NPU.
Ergonomically Designed & Medical Grade 3D Printing Cavity.
Richer and Enhanced Spatial Performance More Accurate Sound Positioning.
Acoustic Tuning with Hi-Fi and Gaming, Highly VDSF Target-Aligned Response, Ultra-low Full Link Nonlinear Distortion.
USB-C Wired Lossless Transmission, Ships USB-C to A Extended Cable.

Specification
Model: RAYS (Dynamic Driver + Planar Magnetic Driver)
Type: USB-C DSP Pro Gaming IEMs with Mic AI Denoise
Series: MOONDROP Gravity - Pro Gaming Series
Driver Configuration:
• 10mm Sapphire Plated Diaphragm Dynamic Driver
• 6mm Annular Planar Magnetic Driver
Impedance: 30Ω ±15% (@1kHz)
Sensitivity: 120dB/Vrms (@1kHz)
Frequency Response: 7Hz–39kHz
Effective Frequency Range: 20Hz–20kHz (IEC60318-4, -3dB)
Total Harmonic Distortion (THD): ≤0.05% (@1kHz)
Earphone Connector: 0.78-2pin
Standard Cable Plug: USB-C
